EREBUS

LED bar with RGBW and DMX functionality

Features & Benefits

• Formed from extruded aluminium with high-performance heat sink
• Excellent life and lumen package
• Can be formed into any shape to suit both client and application
• Available with standard, DALI or DMX control gear
• Choice of 3000k, 4000k & 6000k CCT as standard, other colours available upon request
• RGB and RGBW functionality
• Option of IP65 rated for outdoor applications

Applications

• Hotels
• Receptions
• Circulation areas
• Toilets
• Applications where a decorative appearance is required

Example Installations

EREBUS fittings are used in the following installations:

General

  • Size 17mm width x 8.6mm depth, lengths dependent on application
  • Extruded aluminium body with polycarbonate lens
  • Recessed or surface mounted

Optical

  • Up to 840lm @ 9.6w (400mA) per metre, 1190lm @ 14.3w (700mA) per metre
  • CCT 3000k, 4000k & 6000k (other colours available including RGB & RGBW)
  • CRI >70Ra
  • Beam angle of 110°

Electrical

  • Wattage 9.6w & 14.3w
  • Input voltage 24V
  • Forward current 400mA/700mA

Durability

  • IP20 (IP65 optional)
