EREBUS
LED bar with RGBW and DMX functionality
Features & Benefits
• Formed from extruded aluminium with high-performance heat sink
• Excellent life and lumen package
• Can be formed into any shape to suit both client and application
• Available with standard, DALI or DMX control gear
• Choice of 3000k, 4000k & 6000k CCT as standard, other colours available upon request
• RGB and RGBW functionality
• Option of IP65 rated for outdoor applications
Applications
• Hotels
• Receptions
• Circulation areas
• Toilets
• Applications where a decorative appearance is required
Example Installations
EREBUS fittings are used in the following installations:
General
- Size 17mm width x 8.6mm depth, lengths dependent on application
- Extruded aluminium body with polycarbonate lens
- Recessed or surface mounted
Optical
- Up to 840lm @ 9.6w (400mA) per metre, 1190lm @ 14.3w (700mA) per metre
- CCT 3000k, 4000k & 6000k (other colours available including RGB & RGBW)
- CRI >70Ra
- Beam angle of 110°
Electrical
- Wattage 9.6w & 14.3w
- Input voltage 24V
- Forward current 400mA/700mA
Durability
- IP20 (IP65 optional)
