MINATOR II

MINATOR II

Exterior street and area light

Features & Benefits

• High luminous efficiency of up to 135lm/w
• Strong heat dissipation to ensure long lifespan
• Ultra-durable powder coated finish providing excellent resistance to corrosion, ultraviolet degradation and abrasion
• 40W – 100W input power, 200W high powered version
• IP66 rated
• Swann IP LINK control, DALI and 1-10V dimmable

Applications

• Highways and major roads
• Residential roads
• Pedestrian areas

General

  • RAL 7016 Anthracite Grey
  • Die-cast aluminium body with polycarbonae lens
  • Post-top entry 60mm

Optical

  • Lumen output 5400lm - 26000lm
  • CCT of 2200k - 5700k
  • CRI >70Ra
  • SDCM 3
  • 4 standard roadway beam angles

Electrical

  • Input power of 40W - 200W
  • Efficacy of up to 135lm/w
  • Input voltage 100-277Vac / 200-240Vac (0-10V+DALI)
  • PF >0.92

Durability

  • Operating temp. -40°C to 35°C
  • IP66
  • IK09
