COMFORT LINEAR

COMFORT LINEAR

Suspended, surface & recessed LED profile

Features & Benefits

• Direct, extruded linear profile
• Suitable for surface, recessed or suspended mounting
• Individual or continuous luminaire
• Up to 2400mm in continuous length
• Choice of grey, white or black finish
• Ability to provide full circadian lighting control via the Ambx SmartCore system

Applications

• Care Homes
• Hospitals
• Areas for assisted living

Example Installations

COMFORT LINEAR fittings are used in the following installations:

General

  • 600mm/1200mm/1800mm or 2400mm length x 62mm width x 72mm deep
  • Grey, white or black finish
  • Extruded aluminium with opal diffuser
  • Surface, suspended or recessed mounting

Optical

  • Lumen output of up to 31,000 lm
  • CRI >90Ra
  • SDCM <3
  • 110° beam angle

Electrical

  • Input power of 87W - 348W (max)
  • Efficacy of up to 90lm/w
  • Voltage 220-240V 50/60Hz

Durability

  • Lifespan >50,000 hrs
  • Operating temp. -20°C to 45°C
  • IP20
